2.2.6 Start Menu—Connect—Modem
Connects to the PBX in Interactive mode through the modem.
To access the PBX remotely using this feature, an RMT card must be installed and the Remote—
Analogue Remote (Modem) Floating Extension Number assigned in 2.18.1 [11-1] Main.
This option allows direct entry of connection parameters, for cases where the PC is used to connect
to one or just a few PBXs, and an individual profile for each PBX is not necessary. If you connect to
multiple PBXs and would prefer to choose from among pre-saved profiles instead, see 2.2.8 Start
Menu—Connect—Profile Setup for more details about creating profiles.
To connect to the PBX by Modem
1.
From the start menu, select Connect.
The Login window will be displayed.
2. Select a connection option.
• Select a Profile Name if you want to use a pre-saved profile.
a. Select the profile to use from the drop-down list.
b. If the system password for the PBX has not been stored with the profile, enter it.
If the system password has been stored with the selected profile, it does not need to be
entered.
• To enter the parameters manually, select the PBX Model and confirm that the Modem radio
button is selected.
a. Specify the settings as required. For more details, see the table below.
b. Enter the system password for the PBX.
3. Click Connect.
Connection Settings for Modem
Setting Values Description
Dial Number 1-9, 0, *, #, -, ","
[comma], T, P, W
Enter the telephone number to be dialled to
access the PBX.
T: Converts the Dial Type from Pulse to Tone.
"," [comma], P, W: Inserts a pause.
Dial Type Auto(Tone),
Auto(Pulse), Manual
Specify the outgoing dialling method.
If Manual is chosen, dialling must be done with
a connected telephone.
Comment Max. 40 characters Enter a comment to identify the set of values.
Port COMx Specify the number of the COM port assigned
to the PC's modem interface.
Only available COM ports will be displayed.
Baud Rate (bps) 1200, 2400, 4800, 9600,
19200, 38400
Specify the speed of data transmission.
Modem Initialise – Enter the modem initialise command, and click
Initialise to send the command to the modem.
For more details, refer to your modem's
instruction manual.
