Panasonic KX-TDA100

2.6 Utility
92 PC Programming Manual
2.6.17 Utility—System Reset—Reset by the Command
Updates the main system program and data files stored within the PBX using files taken from the SD
memory card, and resets the connected PBX.
This option is only available at Installer level.
2 copies of each of the main system files can be stored on the SD memory card. The names of these
files are as follows:
When new DSYS/DSSYS/DLSYS and PMPR/PSMPR/PLMPR files are transferred from a connected
PC to the SD memory card using the File Transfer PC to PBX (SD Card) utility (see 2.6.2 Utility—
File Transfer PC to PBX (SD Card)), they are stored as the backup files. To use these files on the
PBX, it is necessary to first swap them with the currently active files on the SD memory card.
Requirements
• This utility only functions on PBXs version 1.005 and later.
KX-TDA30
File Name Description
DSSYS Main system data file. Contains all of the current configuration data
for the PBX.
DSSYS_S Backup main system data file
PSMPR PBX program file. Contains the software to run the MPR board of
the PBX.
PSMPR_S Backup PBX program file
KX-TDA100/KX-TDA200
File Name Description
DSYS Main system data file. Contains all of the current configuration data
for the PBX.
DSYS_SUB Backup main system data file
PMPR PBX program file. Contains the software to run the MPR board of
the PBX.
PMPR_SUB Backup PBX program file
KX-TDA600
File Name Description
DLSYS Main system data file. Contains all of the current configuration data
for the PBX.
DLSYS_S Backup main system data file
PLMPR PBX program file. Contains the software to run the EMPR board of
the PBX.
PLMPR_S Backup PBX program file
