Panasonic KX-TDA100D

Pin Assignments
No. Signal Name Level [V] Function
1
8
1 MOH1 Nonpolar Music on Hold Jack: Port 1
2 MOH1 Nonpolar Music on Hold Jack: Port 1
3 PAG2 Nonpolar External Paging Jack: Port 2
4 PAG1 Nonpolar External Paging Jack: Port 1
5 PAG1 Nonpolar External Paging Jack: Port 1
6 PAG2 Nonpolar External Paging Jack: Port 2
7 MOH2 Nonpolar Music on Hold Jack: Port 2
8 MOH2 Nonpolar Music on Hold Jack: Port 2
Pager
Up to 2 paging devices (user
-supplied) can be connected to the PBX.
CAUTION
External Paging Jacks are SELV ports and should only be connected to approved SELV devices, or in
Australia, via the Line Isolation Unit with the Telecommunications Compliance Label.
Pin Assignments
No. Signal Name Level [V] Function
1
8
1 MOH1 Nonpolar Music on Hold Jack: Port 1
2 MOH1 Nonpolar Music on Hold Jack: Port 1
3 PAG2 Nonpolar External Paging Jack: Port 2
4 PAG1 Nonpolar External Paging Jack: Port 1
5 PAG1 Nonpolar External Paging Jack: Port 1
6 PAG2 Nonpolar External Paging Jack: Port 2
7 MOH2 Nonpolar Music on Hold Jack: Port 2
8 MOH2 Nonpolar Music on Hold Jack: Port 2
PC/Printer (via RS-232C)
The PBX is equipped with an RS
-232C interface. This interface provides communication between the PBX
and the user-supplied devices such as PC or line printers. The RS-232C port is used for system programming,
SMDR, diagnostics and external system database storage (save/load) functions.
CAUTION
To protect the system, keep the following in mind:
1. Make
sure that both connector cases (frame ground) of the RS-232C cross cable (shielded cable) are
conductive. If they are not conductive, make sure that both connector cases of the cable are firmly
connected.
124 Installation Manual
2.9.1 Connection of Peripherals
