2.5.3 DLC16 Card (KX-TDA0172)
Function
16-port digital extension card for DPTs, DSS consoles, and PT
-interface CSs.
LED
Amphenol
To extensions
Accessories and User-supplied Items
Accessories (included): Screws ´ 2, Ferrite core ´ 1
User-supplied (not included): Amphenol connector
Note
• Attach the included ferrite core to the cable. Refer to "2.2.8 Attaching a Ferrite Core
".
• To connect the Amphenol connector, refer to "2.2.9 Fastening Amphenol Connector".
• To use a DLC16 card with DSS consoles or Voice Processing System (VPS), the Local Processor
(LPR) software of the card must be version 7.000 or later.
