System Components
System Components Table
Category Model No. Description
Shelf KX-TDA100D Basic Shelf
Main Processing Card Main Processing Card (DMPR)
DMPR Option Card KX-TDA0196 Remote Card (RMT)
Trunk Cards KX-TDA0180 8-Port Analogue Trunk Card (LCOT8)
KX-TDA0181 16-Port Analogue Trunk Card (LCOT16)
KX-TDA0182 8-Port DID Card (DID8)
KX-TDA0183 4-Port Analogue Trunk Card (LCOT4)
KX-TDA0184 8-Port E & M Trunk Card (E&M8)
KX-TDA0187 T-1 Trunk Card (T1)
KX-TDA0188 E-1 Trunk Card (E1)
KX-TDA0189 8-Port Caller ID/Pay Tone Card (CID/PAY8)
KX-TDA0193 8-Port Caller ID Card (CID8)
KX-TDA0284 4-Port BRI Card (BRI4)
KX-TDA0288 8-Port BRI Card (BRI8)
KX-TDA0290CE/
CJ
PRI Card (PRI30)
KX-TDA0290 PRI Card (PRI23)
KX-TDA0484 4-Channel VoIP Gateway Card (IP-GW4E)
KX-TDA0490 16-Channel VoIP Gateway Card (IP-GW16)
KX-TDA1180 8-Port Analogue Trunk Card with CID (CLCOT8)
KX-TDA1186 8-Port Analogue Trunk with Caller ID Daughter Card
(CLCOT8E)
Extension Cards KX-TDA0143 4 Cell Station Interface Card (CSIF4)
KX-TDA0144 8 Cell Station Interface Card (CSIF8)
KX-TDA0171 8-Port Digital Extension Card (DLC8)
KX-TDA0172 16-Port Digital Extension Card (DLC16)
KX-TDA0470 16-Channel VoIP Extension Card (IP-EXT16)
KX-TDA1176 16-Port Single Line Telephone Extension with Caller
ID and Message Lamp Card (
MCSLC16)
KX-TDA1178 24-Port Single Line Telephone Extension with Caller
ID and Message Lamp Card (
MCSLC24)
2 Installation Manual
System Components
