Panasonic KX-TDA100D - Section 1: Operation

1.1.2 System Connection Diagram
Doorphone & Door Opener
BGM/Music On Hold (MOH)
Pager/
Speaker
Batteries
Voice Processing
System
KX-T7636/
KX-T7633
Remote PC
PC
Printer
Trunk (Telephone Company Lines)
Analogue/BRI/PRI/T1/E1
PBX
SLT
CSPS
Wireless Phone
Fax Machine
PC
USB
DPT
ISDN Telephone
Amplifier
SLT
DPT
DSS Console
KX-T7600 KX-T7600
External Sensor/
External Relay Device
Router
Private
IP Network
PC
IP Softphone
CTI Server
PC
PC
IP-PT
PC
USB
KX-DT346/
KX-DT343
KX-DT300 KX-DT300
Installation Manual 15
1.1.2 System Connection Diagram
