2.4.4 CID8 Card (KX-TDA0193)
Function
8-port
Caller ID signal type FSK/FSK (with Call Waiting Caller ID [Visual Caller ID])/DTMF. To be mounted on
the LCOT8/LCOT16 card.
CID8 Card
inside
Screw
OFF
ON
ON
OFF
SW2
LCOT16 card only
SW1
Accessories and User-supplied Items
Accessories (included): Screws ´ 2
User-supplied (not included): none
Note
Only 1 CID8 card can be mounted on the
LCOT8 card.
Switch Settings (on LCOT8/LCOT16 cards)
Switch Type Usage and Status Definition
Port Setting DIP Keep all DIP switches at default "ON"
positions. Do not change the
positions of these switches.
Note
SW2 is for the LCOT16 card only.
