Item Description
5 Sub Code The 5-digit sub code of the relevant hardware (1XXYY).
• 1: Shelf number
• XX: Slot number
– 00 to 07, 11
(00: DMPR Card Slot; 01 to 07: Free Slots; 11: DLC4
Port on the DMPR Card)
• YY: Physical port number
– For optional service cards except
OPB3 card:
Physical port number (01 to 24) will be displayed.
– For OPB3 card:
Sub slot number (1 to 3) + port number (1 to 4) will be
displayed as follows:
• Sub slot 1 of OPB3: 11 to 14
• Sub slot 2 of OPB3: 21 to 24
• Sub slot 3 of OPB3: 31 to 34
Note
When
there are no parameters for the slot and physical port
numbers, XX and YY will be displayed as "00".
Example: Sub code for DMPR card = 10000
6 Error Message A description of the error.
7 Log Information Displays probable causes of the errors and their solutions.
150 Installation Manual
4.1.5 Troubleshooting by Error Log
