Panasonic KX-TDA50

2.7 [1] Configuration
162 PC Programming Manual
2.7.16 [1-1] Slot—T1 Card Property (KX-TDA100/KX-TDA200/KX-
TDA600 only)
The properties of the T1 card can be specified.
Line Coding
Selects the line coding type of T1 PCM (Pulse Code Modulation) used.
Default
B8ZS
Value Range
B8ZS, AMI
Maintenance Console Location
2.7.16 [1-1] Slot—T1 Card Property (KX-TDA100/KX-TDA200/KX-TDA600 only)
Programming Manual References
None
Feature Manual References
None
Frame Sequence
Selects the type of frame sequence used for communications.
Default
ESF
Value Range
D4, ESF
Maintenance Console Location
2.7.16 [1-1] Slot—T1 Card Property (KX-TDA100/KX-TDA200/KX-TDA600 only)
Programming Manual References
None
Feature Manual References
None
ESF Frame Option
Selects the values for C-bit and D-bit. To enable this setting, Frame Sequence on this screen should
be set to ESF.
