2.5 Utility
PC Programming Manual 63
2.5.13 Utility—IP Extension Statistical Information
Displays accumulated statistical information on both IP extensions and IP-EXT cards.
The displayed items are as follows:
To view IP extension information
1.
From the Utility menu, select IP Extension Statistical Information.
2. From the Card Selection drop-down list, select the slot number.
3. Click Execute.
The statistical information will be displayed.
4. Select an option:
•Click Capture if you want to save the displayed information.
1. Enter a file name, or select a file to overwrite.
2. Click Save.
•Click Clear to erase the information and reset the Collection Started Time.
5. Click Cancel to return to the main screen.
2.5.14 Utility—CS Information
Displays information stored by the PBX regarding each Cell Station (CS).
This option is only available at Installer level, and requires that the target CSIF, DHLC or DLC card be
set to INS status.
The displayed items are as follows:
Item Description
Collection Started Time Date and time the port was last reset.
Port Number of the port.
RTP Receive Packet Counter Total number of packets received.
RTP Receive Lost Packet Counter Total number of packets lost.
RTP Receive Abandoned Packet Counter Total number of packets abandoned.
RTP Arrive Packet Interval (MAX.) [ms] Maximum time taken for a packet to
arrive.
RTP Arrive Packet Interval (MIN.) [ms] Minimum time taken for a packet to
arrive.
Item Description
Shelf-Slot Number of the slot (for KX-TDA600, shelf and slot)
Port Number of the port
CS Name Name of the attached CS
