2.4 Tool
PC Programming Manual 41
2.4.5 Tool—Simplified Voice Message—Check Current Usage
(KX-TDA50 only)
Displays information on the voice messages stored in SVM cards installed in the PBX. For each
message, the type of message and the associated extension are displayed.
To view SVM message status
• From the Tool menu, point to Simplified Voice Message and select Check Current Usage.
2.4.6 Tool—Extension List View
Displays a list of all programmed extension numbers and types.
The types that can be displayed are as follows:
To view extension information
• From the Tool menu, select Extension List View.
2.4.7 Tool—Import
Allows several types of system data files or tables to be imported.
Except for Speed Dial and Caller ID, this option is only available at Installer level.
The files from which data can be imported are files that were previously saved at this or another PBX
using the Export tool (see 2.4.8 Tool—Export), or comma-separated value (CSV) files. Unsupported
file types cannot be opened. PS Registration (KX-TDA600 only) files are saved with the extension
".kex" by default.
Type Detail
Intercom Wired Extension
VM Voice Mail
Portable Station Wireless Extension (Portable Station)
ICDG Incoming Call Distribution Group
WG PS Ring Group
VM (DPT) VM (DPT) Group
VM (DTMF) VM (DTMF) Group
Pager External Pager
MODEM Analog Modem
OGM (DISA) DISA
DSS DSS Console
DPT-I/F CS PT-interface CS
SVM SVM Card
