2.5 Utility
62 PC Programming Manual
Trace information will be displayed.
5. Select an option:
•Click Capture to save the displayed trace information.
•Click Clear to clear the screen display.
6. Click Cancel to return to the main screen.
2.5.12 Utility—Digital Trunk Error Report (KX-TDA100/KX-
TDA200/KX-TDA600 only)
Displays accumulated information on various types of errors occurring on digital CO lines.
This option is only available at Installer level.
The value displayed for each error item is the number of times that each error occurred during the
time period selected. Average values for these items vary depending upon many factors, such as the
equipment being used, and the distance from the telephone company.
The displayed items are as follows:
To view digital CO line information
1.
From the Utility menu, select Digital Trunk Error Report.
2. From the Slot No drop-down list, select the target slot.
• To generate a report on a specific card, select the slot number and card name.
• To generate a report on all matching cards simultaneously, select "ALL".
3. From the Display form drop-down list, select the time period to view.
4. Click Execute.
The error report will be displayed.
Item Description
Time Time of error
Slot Relevant slot and card type
Counter of Digital Trunk
Error Logs logged in
Minor Error Log
Out of SYNC (#300) Digital CO line out of sync (Loss of
Signal)
RAI (#301) Digital CO line RAI signal reception
AIS (#302) Digital CO line Alarm Indication Signal
reception
Frame Failure (#300) Digital CO line frame failure (Loss of
Frame)
Counter of minor
communication error
CRC Cyclic Redundancy Check error
SF Severely errored frame (or Severe
Framing Error)
FE Frame synchronization bit-error
LV Line Code Violation
SL Controlled slip
