2.3 Connect
PC Programming Manual 39
2.3.7 Connect—Disconnect
Closes the connection between the Maintenance Console and the PBX. When this option is chosen,
system data is automatically backed up from the PBX to the SD memory card (see 2.4.1 Tool—SD
memory backup).
To disconnect
1.
From the Connect menu, select Disconnect.
A confirmation message will be displayed.
2. Click Yes.
Port Number 10000–65535 Specify the port number used to access the
PBX via LAN. Enter the same port number that
was input in Maintenance Port Number of
2.7.28 [1-1] Slot—CTI-LINK Card Property
(KX-TDA100/KX-TDA200/KX-TDA600 only)
or 2.7.19 [1-1] Slot—IP-GW Card Property
(KX-TDA50 only).
Connection Settings for LAN
Setting Values Explanation
To Next Page
