2.3 Connect
36 PC Programming Manual
2.3.5 Connect—Profile Setup
Profiles are useful when one PC is used to connect to multiple PBXs. Rather than manually adjusting
the connection settings each time a different PBX is accessed, it is possible to store the connection
settings for several PBXs. Then, when you wish to connect to a specific PBX, you can simply choose
that PBX's profile from the list.
Note that the order of items in this section corresponds to MPR Software File Version 3.2000 or later
of the Maintenance Console. If using an earlier version, please refer to the PC Programming Manual
that came with that version.
The functions of the buttons on this screen are as follows:
Connection Settings for Modem
Setting Values Description
Dial Number 1-9, 0, *, #, "," [comma],
T, P, W *
1
Enter the telephone number to be dialed to
access the PBX.
T: Converts the Dial Type from Pulse to Tone.
"," [comma], P, W: Inserts a pause.
Dial Type Auto(Tone),
Auto(Pulse), Manual
Specify the outgoing dialing method.
If Manual is chosen, dialing must be done with
a connected telephone.
Comment – Enter a comment to identify the set of values.
Port COMx Specify the number of the COM port assigned
to the PC's modem interface.
Only available COM ports will be displayed.
Baud Rate 1200bps, 2400bps,
4800bps, 9600bps,
19200bps, 38400bps
Specify the speed of data transmission.
Modem Initialize – Enter the modem initialize command, and click
Initialize to send the command to the modem.
For more details, refer to your modem's
instruction manual.
*
1
:
T, P and W can only be entered when using MPR Software File Version 3.2000 or later.
Button Function
New Opens the 2.3.6 Connect—Profile Editor window to create a new
profile.
Edit When an existing profile is selected, opens the 2.3.6 Connect—Profile
Editor window to modify the parameters of that profile.
Delete When an existing profile is selected, deletes that profile. A confirmation
message will be displayed.
Close Closes the current window.
