2.7 [1] Configuration
174 PC Programming Manual
Feature Manual References
None
CH
Indicates the channel number (reference only).
Default
Current channel number
Value Range
Channel number
Maintenance Console Location
2.7.17 [1-1] Slot—T1 Port (KX-TDA100/KX-TDA200/KX-TDA600 only)
Programming Manual References
None
Feature Manual References
None
Connection
Indicates the channel status (reference only).
This column offers two ways to open the screen to select the channel command:
• Click the desired cell in the column.
• Select the desired cell in the column, and then click Command.
Default
Current status
Value Range
INS: The channel is in service.
OUS: The channel is out of service.
Fault: The channel is not communicating with the network.
Maintenance Console Location
2.7.17 [1-1] Slot—T1 Port (KX-TDA100/KX-TDA200/KX-TDA600 only)
Programming Manual References
None
Feature Manual References
None
