Panasonic KX-TDA50

2.7 [1] Configuration
PC Programming Manual 81
3. Click Yes to confirm.
The card will be removed.
To change the status (INS/OUS) of a card (Interactive mode only)
1. Move the mouse pointer over the card.
A menu will be shown under the mouse pointer.
2. Select the desired status:
•Click INS to set the card to in-service status.
•Click OUS to set the card to out-of-service status.
To install an option card on an OPB3 card
1. Move the mouse pointer over the card.
A menu will be shown under the mouse pointer.
2. Select Option Card.
The OPB3 Option Card Setup screen will be displayed. See 2.7.27 [1-1] Slot—OPB3 Option
Card Setup (KX-TDA100/KX-TDA200/KX-TDA600 only).
Supported Card Types
KX-TDA50
Card Maximum
Quantity
Supported Slot
Numbers
Card Programming
MPR: Main Processing Card 1 00 2.7.3 [1-1] Slot—MPR Card Property
DHLC4: Pre-installed Super Hybrid
Ports
101
2.7.4 [1-1] Slot—Extension Card
Property
DLC4: 4-Port Digital Extension Card
1
02–04 (Type A
Slots)
HLC4: 4-Port Hybrid Extension Card
PLC4: 4-Port Proprietary Extension
Card
SLC4: 4-Port Single Line Telephone
Extension Card
LCOT4: 4-Port Analog CO Line Card 3 2.7.10 [1-1] Slot—LCO Card Property
DLC8: 8-Port Digital Extension Card
2
05–07 (Type B
Slots)
2.7.4 [1-1] Slot—Extension Card
Property
PLC8: 8-Port Proprietary Extension
Card
SLC8: 8-Port Single Line Telephone
Extension Card
IP-GW4: 4-Channel VoIP Gateway
Card
1
2.7.19 [1-1] Slot—IP-GW Card
Property
IP-EXT4: 4-Channel VoIP Extension
Card
1
2.7.22 [1-1] Slot—IP-Extension Card
Property
