Panasonic KX-UT133

Value Range Max. 40 characters
Note
• An empty string is not allowed.
• If "{mac}" is included in this parameter, it will be replaced with
the unit’s MAC address in lower-case.
• If "{MAC}" is included in this parameter, it will be replaced with
the unit’s MAC address in upper
-case.
• If "{MODEL}" is included in this parameter, it will be replaced
with the unit’s model name.
• If "{fwver}" is included in this parameter, it will be replaced with
the firmware version of the unit.
Default Value Panasonic_{MODEL}/{fwver} ({mac})
Web User Interface Reference SIP User Agent (Page 105)
PHONE_NUMBER_n
Parameter Name Example PHONE_NUMBER_1, PHONE_NUMBER_2
, …, PHONE_NUMBER_6
Value Format String
Description Specifies the phone number to use as the user ID required for
registration to the SIP registrar server.
Note
• When registering using a user ID that is not a phone number,
you should use the "SIP_URI_n" setting.
Value Range Max. 32 characters
Default Value Empty string
Web User Interface Reference Phone Number (Page 106)
SIP_URI_n
Parameter Name Example SIP_URI_1, SIP_URI_2, …, SIP_URI_6
Value Format String
Description Specifies the unique ID used by the SIP registrar server, which consists
of "sip:", a user part, the "@" symbol, and a host part, for example,
"sip:user@example.com
".
Note
• When registering using a user ID that is not a phone number,
you should use this setting.
• In a SIP URI, the user part ("user" in the example above) can
contain up to 63 characters, and the host part ("example.com"
in the example above) can contain up to 127 characters.
Value Range Max. 195 characters (except ", &, ', :, ;,
<, >, and space)
Document Version 2013-03 Administrator Guide 247
5.7.2 SIP Settings
