Panasonic KX-UT133

Tabs
Tabs are the top categories for classifying settings. When you click a tab, the corresponding menu items
and the
configuration screen of the first menu item appear. There are 6 tabs for the Administrator account
and 4 tabs for the User account. For details about the account types, see Access Levels (IDs and
Passwords) in this section.
Menu
The menu displays the sub-categories of the selected tab.
Configuration Screen
Clicking a menu displays the corresponding configuration screen, which contains the actual settings,
grouped into sections. For details, see 4.2 Status to 4.7.6 Restart.
Buttons
The following standard buttons are displayed in the Web user interface:
Button Function
Web Port Close Closes the Web port of the unit and logs you out of the Web user interface after
a confirmation message is displayed.
Save
Applies changes and displays a result message (® see Result Messages in
this section).
Cancel Discards changes. The settings on the current screen will return to the values
they had before being changed.
Refresh Updates the status information displayed on the screen. This button is
displayed in the upper
-right area of the [Network Status]
and [VoIP Status]
screens.
Entering Characters
In the Web user interface, when specifying a name, message, password, or other text item, you can enter any
of the ASCII characters displayed in the following table with a white background.
However, there are additional limitations for certain types of fields as follows:
• Number field
– You may only enter a sequence of numeric characters.
– You cannot leave the field empty.
• IP Address field
– You can enter the IP address using dotted
-decimal notation (i.e., "n.n.n.n" where n=0–255).
Document Version 2013-03 Administrator Guide 25
1.1.6 Web User Interface Programming
