11. Connections with External Devices (Video) – HDMI Devices (HDMI Output)
425
Attaching the Cable Holder
Use of the supplied cable holder prevents detachment of the cable and
damage to the terminals.
•
Put the camera on a stable surface to perform this task.
Example: Attaching to an HDMI cable
1
While pushing (A) (1), slide the clamp portion of the
cable holder to remove it (2).
2
After placing the camera on a stable surface, loosely
mount the cable holder to the mount on the camera (3),
and secure the cable holder by rotating the screws in
the direction of the arrows (4), (5).
To Next Page
