Panasonic PT-RZ570

Chapter 4 Settings — [PROJECTOR SETUP] menu
106 - ENGLISH
3) Press asqw to select the input, and press the <ENTER> button.
[LAST USED] Keeps the input selected last.
[COMPUTER1] Sets the input to COMPUTER1.
[COMPUTER2] Sets the input to COMPUTER2.
[VIDEO] Sets the input to VIDEO.
[DVI-D] Sets the input to DVI-D.
[HDMI1] Sets the input to HDMI1.
[HDMI2] Sets the input to HDMI2.
[DIGITAL LINK] Sets the input to DIGITAL LINK.
[INPUT1] - [INPUT10]
*1
Sets the input to DIGITAL LINK, and switches the input of the Panasonic twisted-pair-cable
transmitter to the specied input.
*1 When the optional DIGITAL LINK output supported device (Model No.: ET-YFB100G, ET-YFB200G) is connected to the projector, its input
name is automatically reected from [INPUT1] to [INPUT10]. When an item that does not reect the input name is selected, it will be disabled.
[RS-232C]
Set the communication condition of the <SERIAL IN> terminal. Refer to “<SERIAL IN> terminal” (x page 163).
1) Press as to select [RS-232C].
2) Press the <ENTER> button.
f The [RS-232C] screen is displayed.
3) Press as to select [INPUT SELECT].
4) Press qw to switch the item.
[PROJECTOR] Performs the RS-232C communication with the <SERIAL IN> terminal of the projector.
[DIGITAL LINK]
Performs the RS-232C communication via the optional DIGITAL LINK output supported device (Model
No.: ET-YFB100G, ET-YFB200G) and the <DIGITAL LINK/LAN> terminal.
5) Press as to select [BAUDRATE].
6) Press qw to switch the item.
f The items will switch each time you press the button.
[9600]
Select the proper speed.[19200]
[38400]
7) Press as to select [PARITY].
8) Press qw to switch the item.
f The items will switch each time you press the button.
[NONE]
Select the parity condition.[EVEN]
[ODD]
Note
f When [INPUT SELECT] is set to [DIGITAL LINK], communication using that serial terminal is available only when the corresponding device
(such as the optional DIGITAL LINK output supported device (Model No.: ET-YFB100G, ET-YFB200G)) is connected to the <DIGITAL LINK/
LAN> terminal.
f When transferring logos via the optional DIGITAL LINK output supported device (Model No.: ET-YFB100G, ET-YFB200G), setting for “NO
SIGNAL SLEEP” of the DIGITAL LINK output supported device should be set to “OFF” to avoid interruption of communication.
f The input communication speed is xed to 9 600 bps when [INPUT SELECT] is set to [DIGITAL LINK].
[FUNCTION BUTTON]
Set the function of the <FUNCTION> button on the remote control.
1) Press as to select [FUNCTION BUTTON].
