Panasonic PT-RZ570

Chapter 7 Appendix — Technical information
ENGLISH - 157
PJLink security authentication
The password used for PJLink is the same as that of the password set for web control.
When using the projector without security authentication, do not set a password for web control.
f For specications related to PJLink, visit the website of Japan Business Machine and Information System
Industries Association.
URL http://pjlink.jbmia.or.jp/english/
Using Art-Net function
Since the network function of the projector supports the Art-Net function, you can control the projector settings
with the DMX controller and application software using the Art-Net protocol.
Channel denition
The following table lists the channel denitions used for controlling the projector with the Art-Net function.
Channel settings can be switched using the [NETWORK] menu → [Art-Net CHANNEL SETTING] (x page 125).
The control details assigned to each channel are listed in the following table.
f Channel assignment for [USER] is in factory default setting. Assignment can be changed.
Channel
Control details
[2] [USER] [1]
CHANNEL1 LIGHT OUTPUT LIGHT OUTPUT SHUTTER
CHANNEL2 INPUT SELECT INPUT SELECT INPUT SELECT
CHANNEL3 NONE NONE NONE
CHANNEL4 NONE NONE NONE
CHANNEL5 NONE NONE POWER
CHANNEL6 NONE NONE LIGHT OUTPUT
CHANNEL7 NONE NONE ENABLE / DISABLE
CHANNEL8 POWER POWER FADE-IN
CHANNEL9 SCREEN ADJUSTMENT SCREEN ADJUSTMENT FADE-OUT
CHANNEL10 NONE NONE NONE
CHANNEL11 ENABLE / DISABLE ENABLE / DISABLE SCREEN ADJUSTMENT
CHANNEL12 NONE NONE NONE
Control details
r LIGHT OUTPUT
This can be set in 256 steps between 100 % and 0 %.
Performance Parameter Default value
100 % 0
0… …
0 % 255
r INPUT SELECT (when [Art-Net CHANNEL SETTING] is set to [1])
Performance Parameter Default value
No operation 0-7
0
COMPUTER1 8-15
COMPUTER2 16-23
VIDEO 24-31
DVI-D 32-39
HDMI1 40-47
DIGITAL LINK 48-55
No operation 56-127
Execute P IN P, USER1 128-135
Execute P IN P, USER2 136-143
Execute P IN P, USER3 144-151
No operation 152-255
