Panasonic PT-RZ570

Chapter 6 Maintenance — [SELF TEST] indications
ENGLISH - 153
[SELF TEST] indications
[SELF TEST] can be checked in the [PROJECTOR SETUP] menu → [STATUS] → [SELF TEST].
The following list shows the alphanumeric symbol that is displayed when an error or a warning has occurred and
its details. Conrm “Action number”, and follow the measure in “Measure for error and warning” (x page 154).
The input supply voltage is displayed only with the numeric value.
Error/warning display Details Action number
U11 Intake temperature warning 1
U12 Optical module temperature warning 1
U13 Exhaust air temperature warning 1
U14 Low temperature warning 2
U16 Temperature warning for the front block of the light source (on the lens side) 1
U18
Temperature warning for the rear block of the light source (on the air exhaust port
side)
1
U21 Intake temperature error 1
U22 Optical module temperature error 1
U23 Exhaust air temperature error 1
U24 Low temperature error 2
U25 Temperature error for the front block of the light source (on the lens side) 1
U27 Temperature error for the rear block of the light source (on the air exhaust port side) 1
H01 Battery replacement for the internal clock 3
H11 Intake air temperature sensor error 4
H12 Optical module temperature sensor error 4
H13 Exhaust air temperature sensor error 4
H14 Temperature sensor error for the front block of the light source (on the lens side) 4
H16
Temperature sensor error for the rear block of the light source (on the air exhaust port
side)
4
F15 Luminance sensor warning 4
F16 Angle sensor error 4
F18 Air pressure sensor error 4
F50 Heat pipe fan 1 warning 4
F51 Heat pipe fan 2 warning 4
F52 DMD fan warning 4
F53 Circuit intake fan warning 4
F54 Exhaust fan 1 warning 4
F55 Exhaust fan 2 warning 4
F56 Center fan warning 4
F61 Light source driver communication error 4
F85 Color wheel error (FM) 4
F86 Color wheel error (FPGA) 4
F90 FPGA conguration error 4
F97 Geometric adjustment board communication error 4
F99 Internal error 4
FE1 Heat pipe fan 1 error 4
FE2 Heat pipe fan 2 error 4
FE3 DMD fan error 4
FE4 Circuit intake fan error 4
FE5 Exhaust fan 1 error 4
FE6 Exhaust fan 2 error 4
FE7 Center fan error 4
FH0 PW ERROR (FM/SUB) 4
FL1 Light source unit error 5
FL5 Light source bank 1 warning 4
FL6 Light source bank 2 warning 4
FL7 Light source bank 3 warning 4
FL8 Light source bank 4 warning 4
Note
f The self-diagnosis display and the details of the malfunction may be different.
