40
7.1.3.2. Analog Amp P.C.B.
Fig. 3 Analog Amp P.C.B.
IC5300
POWER
AMPLlFIER
IC
IC5100
POWER
AMPLlFIER
IC
IC5200
POWER
AMPLlFIER
IC
Analog Amp P.C.B.
Transistor:
Q5749, Q5750,
Q5754
SPEAKER
OUTPUT
Transistor:
Q5747, Q5748
Transistor:
Q5740, Q5741,
Q5742, Q5744
Diode:
D5745, D5755
Muting Circuit
