8 Service Fixture & Tools
8.1. Service Tools and Equipment
Prepare service tools before process service position.
Service Tools Remarks
Analog Amp P.C.B. (CN5500) - SMPS P.C.B. (H5801) REXX0725 (8P cable) (RTL)
Main P.C.B. (CN2009) - Analog Amp P.C.B. (CN5050) REEX0815 (17P FFC) (RTL)
Main P.C.B. (H2901) - SMPS P.C.B. (CN2016) REXX0653-J (14P cable) (RTL)
Main P.C.B. (CN2001) - DVD Module P.C.B. (FP8101) REEX1009 (50P FFC) (RTL)
Main P.C.B. (H2900) - SMPS P.C.B. (CN2017) REXX0724 (8P FFC) (RTL)
