Panasonic SA-PT170PH - Mic PCB Voltage Data

81
11.10. Mic P.C.B.
REF NO.
MODE 12345678
CD PLAY 0 0 0 -6.7 0 0 0 6.8
STANDBY 0 0 0 -6.7 0 0 0 6.8
REF NO.
MODE 12345678910111213141516
CD PLAY 5.2 2.6 0 0 2.7 2.6 0.6 0.6 2.6 2.6 2.6 2.6 2.6 2.6 2.6 2.6
STANDBY 5.2 2.6 0 0 2.7 2.6 0.6 0.6 2.6 2.6 2.6 2.6 2.6 2.6 2.6 2.6
REF NO.
MODE ECB ECB ECB ECB ECB
CD PLAY 0 0 5.1 0 0 5.1 0 0 3.4 0 0 5.1 0 0 0
STANDBY 0 0 5.1 0 0 5.1 0 0 3.4 0 0 5.1 0 0 0
REF NO.
MODE E C B
CD PLAY 0 0 0
STANDBY 0 0 0
Q7101
Q7102
SA-PT170PH/PR MIC P.C.B.
IC7000
IC7100
Q7001 Q7002 Q7003 Q7100
