Ref.
No.
Part No. Part Name & Description Remarks
IC2102 C0AABB000125 IC OP-AMP (HEADPHONES AMP) [M]
IC2104 C0ABBB000230 IC DUAL OP-AMP (WIRELESS CH1
AMP)
[M]
IC2105 C0JBAR000002 IC DUAL 4CH MULTIPLEXER
(WIRELESS CH1 SIGNAL
SELECTOR)
[M]
IC2751 C0ABBB000350 IC OP-AMP [M]
IC2801 C9ZB00000461 IC VIDEO BUFFER [M]
IC2900 C0DAAYY00042 IC SWITCHING REGULATOR [M]
IC2901 C0DAGHG00002 IC +5V REGULATOR [M]
IC2902 C0CBCBC00208 IC +3.3V REGULATOR [M]
IC2903 C0DAAMH00012 IC SWITCHING REGULATOR [M]
IC3901 MN864702 IC HDMI TRANSMITTER [M]
IC3952 C0CBCDC00063 IC TERMINAL VOLTAGE REGULATOR [M]
IC5000 C1BA00000487 IC AUDIO DIGITAL POWER AMP [M]
IC5200 C1BA00000487 IC AUDIO DIGITAL POWER AMP [M]
IC5300 C1BA00000487 IC AUDIO DIGITAL POWER AMP [M]
IC5500 C0JBAB000902 IC INVERTER GATE (CLOCK
GENERATOR)
[M]
IC5501 C0JBAF000716 IC D-TYPE FLIP-FLOP [M]
IC5701 C0DAAMH00004 IC SWITCHING REGULATOR [M]
IC5799 MIP4110MSSCF IC SWITCHING REGULATOR [M]
IC5801 C0DABFC00002 IC SHUNT REGULATOR [M]
IC6901 C0HBB0000057 IC DISPLAY DRIVER [M]
IC7750 C0GAG0000007 IC TRAY MOTOR DRIVE [M]
IC8001 MN2DS0018VP IC DV5 LSI [M]
IC8002 C0CBCDG00003 IC +5V REGULATOR [M]
IC8003 C0ABBB000230 IC DUAL OP-AMP (IPOD AMP) [M]
IC8051 C3ABPG000145 IC 64M SDRAM [M]
IC8111 C0DBZYY00018 IC +3.3V DC-DC CONVERTER [M]
IC8151 C0DBEHG00006 IC +1.2V REGULATOR [M]
IC8251 C0GBG0000048 IC MOTOR DRIVE [M]
IC8421 C0FBBK000050 IC AUDIO DAC [M]
IC8601 C0EBA0000029 IC RESET [M]
IC8606 C0EBE0000456 IC RESET [M]
IC8651 RFKWMHB0G320 IC 32M FLASH MEMORY [SPG]
IC8691 C0JBAA000502 IC AND GATE [M]
IC8695 C0JBAA000502 IC AND GATE [M]
IC8701 C0JBAB000907 IC INVERTER GATE [M]
IC8901 C0JBAA000501 IC AND GATE [M]
IC9001 C0JBAZ001251 IC LATCH [M]
IC9002 C0JBAZ001251 IC LATCH [M]
TRANSISTORS
Q2001 B1GBCFJJ0051 TRANSISTOR [M]
Q2003 B1GBCFLL0037 TRANSISTOR [M]
Q2006 B1GBCFJN0033 TRANSISTOR [M]
Q2010 B1GBCFJJ0051 TRANSISTOR [M]
Q2011 B1GBCFJJ0051 TRANSISTOR [M]
Q2012 B1GBCFJJ0051 TRANSISTOR [M]
Q2013 B1GBCFJJ0051 TRANSISTOR [M]
Q2096 2SD0601AHL TRANSISTOR [M]
Q2097 2SD0601AHL TRANSISTOR [M]
Q2101 B1GFGCAA0001 TRANSISTOR [M]
Q2201 B1GDCFGA0018 TRANSISTOR [M]
Q2801 B1GBCFJN0033 TRANSISTOR [M]
Q2900 B1BABK000001 TRANSISTOR [M]
Q2901 B1BCCG000002 TRANSISTOR [M]
Q2902 B1ADCF000001 TRANSISTOR [M]
Q2903 B1BACG000023 TRANSISTOR [M]
Q2904 B1BACG000023 TRANSISTOR [M]
Q2909 B1ABCF000176 TRANSISTOR [M]
Q2915 B1GBCFJJ0051 TRANSISTOR [M]
Q2919 B1ABCF000176 TRANSISTOR [M]
Q2921 B1ADCF000001 TRANSISTOR [M]
Q2922 B1GBCFJJ0051 TRANSISTOR [M]
Q2923 B1GBCFJJ0051 TRANSISTOR [M]
Q2924 B1GBCFJJ0051 TRANSISTOR [M]
Q3901 2SD1819A0L TRANSISTOR [M]
Q3902 B1CFHA000002 TRANSISTOR [M]
Q3903 B1CFHA000002 TRANSISTOR [M]
Q3941 2SD1819A0L TRANSISTOR [M]
Q3942 2SD1819A0L TRANSISTOR [M]
Ref.
No.
Part No. Part Name & Description Remarks
Q3943 2SD1819A0L TRANSISTOR [M]
Q5101 B1ABCF000176 TRANSISTOR [M]
Q5102 B1ABCF000176 TRANSISTOR [M]
Q5601 B1ABCF000176 TRANSISTOR [M]
Q5602 B1ABCF000176 TRANSISTOR [M]
Q5603 B1ADCE000012 TRANSISTOR [M]
Q5604 B1ABCF000176 TRANSISTOR [M]
Q5640 B1BACD000018 TRANSISTOR [M]
Q5641 B1ABCF000011 TRANSISTOR [M]
Q5642 B1ABCF000011 TRANSISTOR [M]
Q5644 B1ABCF000011 TRANSISTOR [M]
Q5720 2SC3940ARA TRANSISTOR [M]
Q5721 B1ADCF000001 TRANSISTOR [M]
Q5722 B1ABCF000176 TRANSISTOR [M]
Q5802 B1ABCF000176 TRANSISTOR [M]
Q5803 2SC3940ARA TRANSISTOR [M]
Q5860 B1ADCF000001 TRANSISTOR [M]
Q5861 B1ABCF000176 TRANSISTOR [M]
Q5862 B1ABCF000176 TRANSISTOR [M]
Q5898 B1ABCF000176 TRANSISTOR [M]
Q5899 B1ABCF000176 TRANSISTOR [M]
Q6901 B1GBCFJN0033 TRANSISTOR [M]
Q6903 B1GDCFJJ0047 TRANSISTOR [M]
Q7101 B1GFGCAA0001 TRANSISTOR [M]
Q7750 B1GBCFJJ0051 TRANSISTOR [M]
Q8321 2SB1218ARL TRANSISTOR [M]
Q8325 2SB1218ARL TRANSISTOR [M]
Q8331 2SB1218ARL TRANSISTOR [M]
Q8335 2SB1218ARL TRANSISTOR [M]
Q8341 2SB1218ARL TRANSISTOR [M]
Q8551 2SD1819A0L TRANSISTOR [M]
Q8552 B1ADGB000008 TRANSISTOR [M]
Q8561 2SD1819A0L TRANSISTOR [M]
Q8562 B1ADGB000008 TRANSISTOR [M]
Q9001 B3NAA0000098 CAM SENSOR [M]
Q9101 B3NAA0000082 POSITION SENSOR [M]
Q9102 B3NAA0000102 PULSE SENSOR [M]
Q9103 B3NAB0000027 DISC SENSOR [M]
QR5801 B1GBCFJN0033 TRANSISTOR [M]
QR5810 B1GBCFLL0037 TRANSISTOR [M]
QR8111 XP0621400L CHIP TRANSISTOR [M]
QR8420 UNR521100L CHIP TRANSISTOR [M]
QR8571 UNR511V00L CHIP TRANSISTOR [M]
PC5701 B3PBA0000402 PHOTO COUPLER [M]
PC5702 B3PBA0000402 PHOTO COUPLER [M]
PC5720 B3PBA0000402 PHOTO COUPLER [M]
PC5799 B3PBA0000402 PHOTO COUPLER [M]
DIODES
D1 MA2J72800L DIODE [M]
D2005 B0ACCK000005 DIODE [M]
D2007 B0ACCK000005 DIODE [M]
D2008 B0ACCK000005 DIODE [M]
D2009 B0JCAE000001 DIODE [M]
D2010 B0JCAE000001 DIODE [M]
D2011 B0JCAE000001 DIODE [M]
D2601 B0ACCK000005 DIODE [M]
D2602 B0ACCK000005 DIODE [M]
D2751 B0BC5R000009 DIODE [M]
D2752 B0ACCK000005 DIODE [M]
D2753 B0ACCK000005 DIODE [M]
D2901 B0BC035A0007 DIODE [M]
D2903 B0EAMM000057 DIODE [M]
D2904 B0JCPD000025 DIODE [M]
D2906 B0JAME000029 DIODE [M]
D2908 B0EAMM000057 DIODE [M]
D2909 MAZ82400HL DIODE [M]
D2910 B0ECKM000016 DIODE [M]
D2911 B0ECKM000016 DIODE [M]
D2912 B0BC3R400001 DIODE [M]
142
SA-PT750P / SA-PT750PC
