26.1. Component Parts List
Ref.
No.
Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 J3CCBB000007 TUNER PACK [M]
2 REXX0558 11P FLAT WIRE [M]
3 REXX0554 PRIMARY WIRE (BLACK) [M]
4 REXX0555 PRIMARY WIRE (RED) [M]
5 L6FAJCCH0007 DC FAN MOTOR [M]
6 REEX0662 50P FFC WIRE [M]
7 REEX0663 7P FFC WIRE [M]
8 REEX0664 17P FFC WIRE [M]
9 REEX0665 14P FFC WIRE [M]
10 REEX0666 28P FFC WIRE [M]
11 RSCX0153-1 XM SHIELD PLATE [M]
12 REEX0667 17P FFC WIRE [M]
13 REEX0668 28P FFC WIRE (FL) [M]
14 REEX0669 10P FFC (MAIN) [M]
15 REEX0749 12P FFC WIRE [M]
16 REEX0785 11P FFC WIRE [M]
17 REXX0556 8P FLAT WIRE [M]
20 RGPX0280A-K FRONT PANEL [M]PC
20 RGPX0280-K FRONT PANEL [M]P
21 RGQX0027-1 TOP FFC COVER [M]
22 RGRX0061A-A3 REAR PANEL [M]P
22 RGRX0061A-B2 REAR PANEL [M]PC
23 RGUX0695-K OPEN/CLOSE BUTTON [M]
24 RGUX0697-K EXCHANGE BUTTON [M]
25 RGUX0698-S VOLUME BUTTON(LARGE) [M]
26 RGUX0699-K 5 DISC BUTTON [M]
27 RHD26046 SCREW [M]
28 RHD30007-K2J SCREW [M]
29 RHD30070 EARTH TERMINAL [M]
30 RHD30107-1 SCREW [M]
31 RHD30111-3 SCREW [M]
32 RHD30119-S SCREW [M]
33 RKA0059-K LEG RUBBER [M]
34 RKMX0118B-K1 TOP CABINET [M]
35 RKWX0266-Q FL WINDOW [M]
36 RMAX0106 MECHA BRACKET [M]
37 RMAX0118 PCB BRACKET [M]
38 RMC0465 TR SPRING [M]
39 RMKX0126 BOTTOM CHASSIS [M]
40 RMKX0127-K TRANSMITTER CHASSIS [M]
42 RMNX0166 HOLDER A [M]
43 RMNX0171 HOLDER B [M]
44 RMNX0210 TRAY GUIDE L [M]
45 RMNX0211 TRAY GUIDE R [M]
46 RMNX0231 D-PORT COVER [M]
48 RMQX0233-K FAN COVER [M]
49 RMX0274 TRAY SUPPORT R [M]
50 RMYX0191 HEATSINK EXTRUSSION [M]
51 RMX0275 TRAY SUPPORT L [M]
52 RMY0285 SMALL HEAT SINK [M]
53 RMZ0339 COVER [M]
54 RWJ1108090XX 8P (PANEL TO PANEL) [M]
55 RXQX0041 CUSHION ASSY [M]
56 RXXX0085 HEATSINK UNIT A [M]
57 XTB3+8JFJ SCREW [M]
58 RXXX0086 HEATSINK UNIT B [M]
59 RXXX0087 HEATSINK UNIT C [M]
60 RXXX0098 HEATSINK UNIT D [M]
61 RYQX0284-K TRAY LID ASS’Y [M]
62 XTB3+10JFJ SCREW [M]
63 XTB3+16JFJ SCREW [M]
64 XTB3+6JFJ SCREW [M]
65 XTW3+8TFJ SCREW [M]
66 RMNX0238 PC SHEET [M]
67 RMNX0149 FL HOLDER [M]
69 J0KD00000121 FERRITE CORE [M]
TRAVERSE DECK
Ref.
No.
Part No. Part Name & Description Remarks
301 RDG0562 PULLEY GEAR [M]
302 RDG0563-1 REALAY GEAR A [M]
303 RDG0564 RELAY GEAR B [M]
304 RDG0565 DRIVE GEAR A [M]
305 RDG0566 DRIVE GEAR B [M]
306 RDG0567 PULSE GEAR [M]
307 RDG0568-1 OPEN LOCK GEAR [M]
308 RDG0569-1 CLOSE LOCK GEAR [M]
309 RDG0570 CAM GEAR [M]
310 RDV0072 LOADING BELT [M]
311 RDV0073 TRAY BELT [M]
312 REM0112 LOADING MOTOR ASS’Y [M]
313 RGQ0359-K1 ROTARY TRAY [M]
314 RGQ0446-K TRAY BASE [M]
315 RHM0003-J MAGNET [M]
316 RMB0842 TRAY SPRING [M]
317 RMC0387 SUPPORT SPRING [M]
318 RME0384 CLOSE LOCK GEAR SPRING [M]
319 RMF0182 TRAY FELT [M]
320 RMF0324-1 BLOCK SHEET [M]
321 RMG0615-K CUSHION SHEET [M]
322 RMG0620-K CUSHION RUBBER [M]
323 RMK0555-2 MECHA BASE [M]
324 RML0646 CHANGE LEVER [M]
325 RMM0254-2 SLIDE PLATE R [M]
326 RMM0255 SLIDE PLATE L [M]
327 RMM0256-2 BLOCK BASE [M]
328 RMR1446-X CLAMPER [M]
329 RMR1447-X MAGNET HOLDER [M]
330 RMR1507-X SUPPORT PIECE [M]
331 RMS0123-1 FIXED PIN B [M]
332 RMS0802-2J DRIVE SHAFT [M]
333 XTB3+10JFJ SCREW [M]
334 XTN26+14JFJK SUPPORT PIECE SCREW [M]
335 XTN26+8GFJ ADDITION SCREW [M]
336 XTV2+6GFJ PCB SCREW [M]
337 XTWS3+10SFJ SCREW [M]
338 XWG6FFJ WASHER [M]
341 REEX0670 11P FFC WIRE [M]
342 RAE2022Z-S DT6J TRAVERSE UNIT [M]
343 RMG0598A-K FLOATING RUBBER [M]
344 RMR1753-X MIDDLE CHASSIS [M]
345 RMS0789 FIXED PIN [M]
PRINTED CIRCUIT BOARDS
REPX0563A DVD MODULE P.C.B. [M]
(RTL)
REPX0590A XM MODULE P.C.B. [M]
(RTL)
REPX0575A MAIN/PANEL/KEY/WIRELESS
ADAPTER/TRAY P.C.B.
[M]
(RTL)P
REPX0575D MAIN/PANEL/KEY/WIRELESS
ADAPTER/TRAY P.C.B.
[M]
(RTL)PC
REPX0601A D-PORT P.C.B. [M]
(RTL)
REPX0560H D-AMP P.C.B. [M]
(RTL)
REPX0568A SMPS/AC-INLET P.C.B. [M]
(RTL)
REP3465B LOADING MOTOR P.C.B. [M]
(RTL)
REP3466B TRAY MOTOR P.C.B. [M]
(RTL)
REP3466B SENSOR P.C.B. [M]
(RTL)
INTEGRATED CIRCUITS
IC1 C1AB00002670 IC XM SAT RADIO DRIVER [M]
IC2 C0DBZYE00002 IC POWER SUPPLY [M]
IC3 C0FBBY000027 IC 2CH D-A CONVERTER [M]
IC2001 C2CBYY000442 IC SYSTEM CONTROL [M]
IC2002 C0GAG0000007 IC LOADING MOTOR DRIVE [M]
IC2101 C1AB00002735 IC AUDIO SIGNAL PROCESSOR [M]
141
SA-PT750P / SA-PT750PC
