Panasonic SA-PT750PC - XM Module P.C.B; Panel P.C.B; D-Port, Tray, Loading Motor, Tray Motor & Sensor P.C.B

15.5. XM Module P.C.B.
Ref No.
MODE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
CD PLAY 3.3 0 3.3 3.3 3.1 0 0.3 3.3 0 0 3.3 0 3.3 0 3.3 0 3.3 1.3 1.3 3.3
STANDBY 3.3 0 3.3 3.3 3.2 0 0.2 3.3 0 0 3.3 0 3.3 0 3.3 0 3.3 1.3 1.3 3.3
Ref No.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
CD PLAY 0 1.3 1.3 0 0 1.3 3.3 1.2 0.3 0 0 0 3.3 0 3.2 3.3 0 0 1.7 3.3
STANDBY 1.3 1.3 1.3 0 0 1.3 3.3 1.2 0.2 0 0 0 3.3 0 3.2 3.3 0 0 1.7 3.3
Ref No.
MODE 41 42 43 44 45 46 47 48
CD PLAY 1.7 0 1.7 3.3 0.3 3.3 0.3 0
STANDBY 1.7 0 1.7 3.3 0.2 3.3 0.2 0
Ref No.
MODE 12345678
CD PLAY 0 5.2 5.2 0 1.8 5.2 5.2 5.2
STANDBY 0 5.2 5.2 0 1.7 5.2 5.2 5.2
Ref No.
MODE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
CD PLAY 1.7 1.7 0 1.7 5 3.2 0 5.2 5.2 2.6 2.6 2.6 0 5.2 0.2 5.2
STANDBY 1.7 1.7 0 1.7 5 3.2 0 5.2 5.2 2.6 2.6 2.6 0 5.2 0.1 5.2
IC2
IC3
SA-PT750P/PC XM MODULE P.C.B.
IC1
IC1
IC1
15.6. Panel P.C.B.
Ref No.
MODE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
CD PLAY 0 0 0 5 3.1 2 2 4.1 2.8 2 2 0 5.2 -24.5 -24.5 -22.1 -22.1 15.5 22.1 -14.9
STANDBY 5 0 0 0 3.1 2.2 4.9 0 0 2.2 2.2 0 5.2 -24.5 -24.5 -24.5 -22.1 -12.4 -10 -172
Ref No.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
CD PLAY -24.6 -24.6 -24.6 -19.7 -17.3 -24.6 -24.6 -24.6 19.8 -25 -17.5 -17.5 -22.4 -22.4 -22.3 -22.4 -22.4 -22.4 -22.4 -22.4
STANDBY -24.5 -24.5 -22.1 -12.4 -10.1 -22.1 -24.5 -22.1 -10.1 -24.9 -15 -12.6 -22.3 -22.3 -22.3 -22.3 -22.3 -22.3 -22.3 -22.3
Ref No.
MODE 41 42 43 44
CD PLAY -22.4 -22.4 5.2 0
STANDBY -22.3 -22.3 5.2 0
Ref No.
MODE E C B E C B
CD PLAY 0 4.9 0 4.9 -0.6 4.9
STANDBY 0 5.2 0 5.2 -0.8 5.2
IC6901
IC6901
SA-PT750P/PC PANEL P.C.B.
IC6901
Q6901 Q6903
15.7. D-Port, Tray, Loading Motor, Tray Motor & Sensor P.C.B.
Ref No.
MODE 12345 12345678
CD PLAY 0 5.2 0 0 - 3.5 3.5 3.5 0 3.5 3.5 3.5 7.0
STANDBY 0 5 0 0
-
3.4 3.3 3.5 0 3.3 3.5 3.5 7.1
Ref No.
MODE 1234567
8
9
CD PLAY 0 0 0 0 8.4 8.9 5
0
5
STANDBY 0 0 0 0 8.5 8.9 4.9
0
4.9
Ref No.
MODE 123456
E
CB
CD PLAY 0 4.9 0 0 4.9 0
0
04.5
STANDBY04.90 04.90
0
04.5
Ref No.
MODE 1234
CD PLAY 1.2 4.5 0 0
STANDBY 0.2 4.8 0 0
Ref No.
MODE 1234 1234
CD PLAY 1.2 0 4.7 0 2.5 1.2 0.1 0
STANDBY 0.1 0 4.8 0 0.4 -0.2 4.8 0
Ref No.
MODE1234
CD PLAY 3.7 2.5 0 0.2
STANDBY 0.2 0.4 0 4.7
Q7750
SA-PT750P/PC TRAY P.C.B.
Q9101 Q9102
Q9103
SA-PT750P/PC SENSOR P.C.B.
SA-PT750P/PC D-PORT P.C.B.
IC8002 IC8003
IC7750
SA-PT750P/PC TRAY MOTOR P.C.B.
Q9001
SA-PT750P/PC LOADING MOTOR P.C.B.
Q7101
85
SA-PT750P / SA-PT750PC
