Panasonic SC-HC40PC - Page 129

129
CN7001 K1MN16B00154 16P CONNECTOR 1
CN7002 K1MN25AA0004 25P CONNECTOR 1 V.MAIN
CN7002 K1MN25B00019 25P CONNECTOR 1 CD
SERVO
P901 K1MN22BA0005 22P CONNECTOR 1
P903 K1FY104B0011 USB CONNECTOR 1
P6803 K1KA07BA0061 7P CONNECTOR 1
COILS AND INDUC-
TOR
L1 G1C100M00045 INDUCTOR 1
L2 G1C100M00045 INDUCTOR 1
L6 G0AR76Y00003 COIL 1
L7 G0AR76Y00003 COIL 1
L8 G0AR76Y00003 COIL 1
L9 G0AR76Y00003 COIL 1
L51 G1CR18JA0020 INDUCTOR 1
L52 G2A380Y00001 COIL 1
L101 J0JBC0000030 INDUCTOR 1
L102 J0JYB0000013 INDUCTOR 1
L103 J0JYB0000013 INDUCTOR 1
L114 J0JBC0000030 INDUCTOR 1
L212 J0JBC0000030 INDUCTOR 1
L213 J0JBC0000030 INDUCTOR 1
L214 J0JBC0000030 INDUCTOR 1
L219 J0JBC0000030 INDUCTOR 1
L220 J0JBC0000030 INDUCTOR 1
L242 J0JBC0000030 INDUCTOR 1
L258 J0JBC0000030 INDUCTOR 1
L302 J0JHC0000034 INDUCTOR 1
L303 J0JBC0000030 INDUCTOR 1
L314 J0JBC0000030 INDUCTOR 1
L321 J0JBC0000030 INDUCTOR 1
L322 J0JBC0000030 INDUCTOR 1
L323 J0JBC0000030 INDUCTOR 1
L324 J0JBC0000030 INDUCTOR 1
L325 J0JBC0000030 INDUCTOR 1
L350 J0JBC0000030 INDUCTOR 1
L381 J0JHC0000034 INDUCTOR 1
L382 J0JHC0000034 INDUCTOR 1
L412 J0JBC0000030 INDUCTOR 1
L419 J0JBC0000030 INDUCTOR 1
L442 J0JBC0000030 INDUCTOR 1
L458 J0JBC0000030 INDUCTOR 1
L501 J0JHC0000034 INDUCTOR 1
L900 G1C100K00019 INDUCTOR 1
L900 J0JBC0000030 INDUCTOR 1
L951 J0JBC0000019 INDUCTOR 1
L952 J0JBC0000019 INDUCTOR 1
L953 J0JBC0000019 INDUCTOR 1
L954 J0JBC0000019 INDUCTOR 1
L955 J0JBC0000019 INDUCTOR 1
L956 J0JBC0000019 INDUCTOR 1
L957 J0JBC0000019 INDUCTOR 1
L958 J0JBC0000019 INDUCTOR 1
L1000 G0C390JA0055 INDUCTOR 1
L1001 J0JBC0000041 INDUCTOR 1
L1001 J0JFC0000006 INDUCTOR 1
L1002 J0JFC0000006 INDUCTOR 1
L1003 J0JGC0000071 INDUCTOR 1
L1004 J0JGC0000071 INDUCTOR 1
L1005 J0JGC0000071 INDUCTOR 1
L1006 J0JGC0000071 INDUCTOR 1
L1007 J0JGC0000071 INDUCTOR 1
L1008 J0JFC0000006 INDUCTOR 1
L1009 J0JFC0000006 INDUCTOR 1
L1010 J0JGC0000071 INDUCTOR 1
L1011 J0JFC0000006 INDUCTOR 1
L1032 J0JBC0000015 INDUCTOR 1
L2911 G0A101ZA0028 COIL 1
L2913 G0A100GA0013 COIL 1
L6802 G0C3R3JA0055 INDUCTOR 1
L6806 G0C101JA0055 INDUCTOR 1
Safety Ref. No. Part No. Part Name &
Description
Qty Remarks
LB51 J0JBC0000032 INDUCTOR 1
FILTERS
L5701 G0B453G00003 FILTER 1
TRANSFORMERS
T1000 G4D1A0000117 SWTCHING TRANS-
FORMER
1
T5701 ETS28BH156AC TRANSFORMER 1
T5751 ETS19AB221AG SUB TRANSFORMER 1
PHOTO COUPLER
PC5720 B3PBA0000402 PHOTO COUPLER 1
EARTH TERMINALS
ZJ5702 K4CZ01000027 TERMINAL 1
ZJ5802 K4CZ01000027 TERMINAL 1
MICROPHONE
M330 L0CBAB000124 MICROPHONE 1
REMOTE CONTROL
SENSOR
IR921 B3RAC0000017 REMOTE CONTROL
SENSOR
1
OSCILLATOR
X51 H0A327200097 CRYSTAL OSCILLA-
TOR
1
X801 H0A327200097 CRYSTAL OSCILLA-
TOR
1
X802 H2B800400005 CRYSTAL OSCILLA-
TOR
1
X900 H0A120500009 CRYSTAL OSCILLA-
TOR
1
X7201 H0H169500013 CRYSTAL OSCILLA-
TOR
1
RELAY
RY5701 K6B1AEA00003 RELAY 1
FL DISPLAY
FL6801 A2BB00000172 LCD DISPLAY 1
FUSE
F1 K5D302AQ0003 FUSE 1
FUSE HOLDERS
ZA5701 K3GE1ZZ00001 FUSE HOLDER 1
ZA5702 K3GE1ZZ00001 FUSE HOLDER 1
FUSE PROTECTORS
FP1000 K5H7512A0010 PROTECTOR 1
THERMISTORS
TH5701 D4CC11040013 THERMISTOR 1
TH5702 D4CAA5R10001 THERMISTOR 1
JACKS
JK51 K4ZZ02000103 JK FM ANT 1
Safety Ref. No. Part No. Part Name &
Description
Qty Remarks
