130
JK52 K4AC02B00042 JK AM ANT 1
JK951 K2HC1YYB0033 JK AUX 1
JK952 K2HC1YYB0033 JK HEADPHONE 1
P5701 K2AB2B000007 AC INLET 1
CHIP JUMERS
L232 D0GBR00JA008 0 1/16W 1
L383 D0GBR00JA008 0 1/16W 1
L384 D0GBR00JA008 0 1/16W 1
L385 D0GBR00JA008 0 1/16W 1
L1021 D0GBR00JA008 0 1/16W 1
L1022 D0GBR00JA008 0 1/16W 1
L1023 D0GBR00JA008 0 1/16W 1
L1024 D0GBR00JA008 0 1/16W 1
L1025 D0GBR00JA008 0 1/16W 1
L1026 D0GBR00JA008 0 1/16W 1
L1027 D0GBR00JA008 0 1/16W 1
L1028 D0GBR00JA008 0 1/16W 1
L1029 D0GBR00JA008 0 1/16W 1
L1030 D0GBR00JA008 0 1/16W 1
L1031 D0GBR00JA008 0 1/16W 1
L1033 D0GBR00JA008 0 1/16W 1
LB840 D0GBR00JA008 0 1/16W 1
LB841 D0GBR00JA008 0 1/16W 1
LB843 D0GBR00JA008 0 1/16W 1
LB845 D0GBR00JA008 0 1/16W 1
LB846 D0GBR00JA008 0 1/16W 1
LB848 D0GBR00JA008 0 1/16W 1
LB850 D0GBR00JA008 0 1/16W 1
LB852 D0GBR00JA008 0 1/16W 1
LB930 D0GBR00JA008 0 1/16W 1
LB932 D0GBR00JA008 0 1/16W 1
LB933 D0GBR00JA008 0 1/16W 1
LB934 D0GBR00JA008 0 1/16W 1
LB935 D0GBR00JA008 0 1/16W 1
LB936 D0GBR00JA008 0 1/16W 1
LB938 D0GBR00JA008 0 1/16W 1
LB951 D0GBR00JA008 0 1/16W 1
LB952 D0GBR00JA008 0 1/16W 1
K502 D0GDR00JA017 0 1/10W 1
K503 D0GDR00JA017 0 1/10W 1
K505 D0GDR00JA017 0 1/10W 1
K506 D0GBR00JA008 0 1/16W 1
K600 D0GBR00JA008 0 1/16W 1
K5721 D0GBR00JA008 0 1/16W 1
W1 D0GBR00JA008 0 1/16W 1
W2 D0GBR00JA008 0 1/16W 1
W3 D0GBR00JA008 0 1/16W 1
W10 D0GDR00JA017 0 1/10W 1
W15 D0GDR00JA017 0 1/10W 1
W17 D0GDR00JA017 0 1/10W 1
W18 D0GDR00JA017 0 1/10W 1
W19 D0GDR00JA017 0 1/10W 1
W21 D0GDR00JA017 0 1/10W 1
W22 D0GDR00JA017 0 1/10W 1
W23 D0GBR00JA008 0 1/16W 1
W91 D0GDR00JA017 0 1/10W 1
W1023 D0GBR00JA008 0 1/16W 1
RESISTORS
LB7262 D0GB221JA008 220 1/16W 1
LB7263 D0GB221JA008 220 1/16W 1
LB7264 D0GB221JA008 220 1/16W 1
R1 D0GB223JA008 22K 1/16W 1
R2 D0GB223JA008 22K 1/16W 1
R3 D0GB223JA008 22K 1/16W 1
R7 D0GB392JA008 3.9K 1/16W 1
R9 D0GB183JA008 18K 1/16W 1
R11 D0GB103JA008 10K 1/16W 1
R12 D0GB104JA008 100K 1/16W 1
R13 D0GB104JA008 100K 1/16W 1
Safety Ref. No. Part No. Part Name &
Description
Qty Remarks
R16 D0GD682JA017 6.8K 1/10W 1
R17 D0GD682JA017 6.8K 1/10W 1
R18 D0GD152JA017 1.5K 1/10W 1
R19 D0GD152JA017 1.5K 1/10W 1
R20 D0GD183JA017 18K 1/10W 1
R21 D0GD183JA017 18K 1/10W 1
R22 D0GB102JA008 1K 1/16W 1
R23 D0GB225JA008 2.2M 1/16W 1
R24 D0GB102JA008 1K 1/16W 1
R51 D0GB102JA008 1K 1/16W 1
R52 D0GB102JA008 1K 1/16W 1
R53 D0GA472JA023 4.7K 1/16W 1
R54 D0GA472JA023 4.7K 1/16W 1
R55 D0GA221JA023 220 1/16W 1
R56 D0GB221JA007 220 1/10W 1
R57 D0GA102JA023 1K 1/16W 1
R59 D0GB222JA008 2.2K 1/16W 1
R61 D0GB473JA008 47K 1/16W 1
R62 D0GB473JA008 47K 1/16W 1
R64 D0GBR00JA008 0 1/16W 1
R101 D0GBR00JA008 0 1/16W 1
R102 D0GB394JA008 390K 1/16W 1
R103 D0GB123JA008 12K 1/16W 1
R104 D0GB222JA008 2.2K 1/16W 1
R105 D0GDR00JA017 0 1/10W 1
R106 D0GDR00JA017 0 1/10W 1
R117 D0GD102JA017 1K 1/10W 1
R118 D0GD122JA017 1.2K 1/10W 1
R119 ERJ6GEYJ104V 100K 1/8W 1
R120 ERJ6GEYJ104V 100K 1/8W 1
R121 D0GD392JA017 3.9K 1/10W 1
R122 D0GD392JA017 3.9K 1/10W 1
R123 D0GD392JA017 3.9K 1/10W 1
R124 D0GD392JA017 3.9K 1/10W 1
R125 D0GD820JA017 82 1/10W 1
R126 D0GD820JA017 82 1/10W 1
R137 D0GB221JA008 220 1/16W 1
R138 D0GB103JA008 10K 1/16W 1
R139 D0GB103JA008 10K 1/16W 1
R140 D0GB102JA008 1K 1/16W 1
R206 D0GB682JA008 6.8K 1/16W 1
R220 D0GB561JA008 560 1/16W 1
R221 D0GB472JA008 4.7K 1/16W 1
R222 D0GB682JA008 6.8K 1/16W 1
R230 D0GB272JA008 2.7K 1/16W 1
R253 D0GDR00JA017 0 1/10W 1
R254 D0GD332JA017 3.3K 1/10W 1
R255 D0GD471JA017 470 1/10W 1
R256 ERJ6GEYJ104V 100K 1/8W 1
R257 D0GD123JA017 12K 1/10W 1
R258 D0GD223JA017 22K 1/10W 1
R260 ERJ6GEYJ104V 100K 1/8W 1
R261 D0GD820JA017 82 1/10W 1
R262 D0GD820JA017 82 1/10W 1
R263 D0GD392JA017 3.9K 1/10W 1
R264 D0GDR00JA017 0 1/10W 1
R267 D0GDR00JA017 0 1/10W 1
R272 J0JBC0000030 INDUCTOR 1
R273 J0JBC0000030 INDUCTOR 1
R274 D0GB223JA008 22K 1/16W 1
R275 D0GB223JA008 22K 1/16W 1
R300 D0GB221JA008 220 1/16W 1
R301 D0GB221JA008 220 1/16W 1
R303 D0GB103JA008 10K 1/16W 1
R304 D0GB223JA008 22K 1/16W 1
R305 D0GB223JA008 22K 1/16W 1
R306 D0GB473JA008 47K 1/16W 1
R307 D0GB473JA008 47K 1/16W 1
R308 D0GB473JA008 47K 1/16W 1
R309 D0GB223JA008 22K 1/16W 1
R310 D0GB223JA008 22K 1/16W 1
R311 D0GB473JA008 47K 1/16W 1
R312 D0GB103JA008 10K 1/16W 1
Safety Ref. No. Part No. Part Name &
Description
Qty Remarks
