24
7.3.2. Doctor Mode Table 2
Item
FL Display
Key Operation
Mode Name Description Front Key
FL Display Test To check the FL segments
display (All segments will
light up)
In Doctor Mode:
1. Press [1] button on remote con-
trol.
To cancel, press [0] button on remote
control.
To exit Doctor Mode, press but-
ton on main unit or remote control.
Volume Setting To check for volume setting
during this mode, Bass &
treble is set to 0dB & EQ is
switch off.
In Doctor Mode:
1. Press [7] button on remote control.
To exit Doctor Mode, press but-
ton on main unit or remote control.
In Doctor Mode:
2. Press [8] button on remote control.
To exit Doctor Mode, press but
-
ton on main unit or remote control.
In Doctor Mode:
3. Press [9] button on remote control.
To exit Doctor Mode, press but-
ton on main unit or remote control.
Mecha Sliding Panel
Reliability
To check the operation of
sliding Panel.
Sequence as follow :
1. Panel set to close
position.
2. CD Open & stop at left
position for 1s.
3. CD Close & stop at
centre position for 1s.
In Doctor Mode:
1.Press[ ]followby[2]&then
[1] button on remote control.
To cancel, press [0] button on remote
control.
To exit Doctor Mode, press but-
ton on main unit or remote control.
CD Traverse Un
it Test
Mode
To check for the traverse unit
operation. In this mode, the
first & last track is access &
read. (TOC). It fails when
TOC is not completed by IOS
or the traverse is out of
focus.
In Doctor Mode:
1. Press [ ], [1], [2] button on
remote control.
To cancel, press [0] button on remote
control.
To exit Doctor Mode, press but-
ton on main unit or remote control.
(For more information,
please refer to Section 7.3.4.)
CD Auto Adjustment
Display
To display result of self
adjustment for CD.
The [NO DISC] display will appear after 3s,
In Doctor Mode:
1. Press [ ], [1], [4] button on
remot
e control.
To cancel, press [0] button on remote
control.
To exit Doctor Mode, press but-
ton on main unit or remote control.
