Parker AC10 series Quick Start Guide

Parameter List and Default Settings 10-2
Function
Code
Function Denition Setting Range Mfr’s Value Change
F121 Reserved
F122
Reverse Running
Forbidden
0: False; 1: True 0
X
F123
Negative Frequency
is Valid in Combined
Speed Control Mode.
0: False; 1: True 0
X
F124 Jogging Frequency F112-F111 5.00Hz
√
F125 Jogging Accel Time 0.1-3000 s
Subject
to inverter
model
√
F126 Jogging Decel Time 0.1-3000 s
√
F127 Skip Frequency A 0.00-590.0 Hz 0.00
√
F128 Skip Width A ±2.50 Hz 0.00
√
F129 Skip Frequency B 0.00-590.0 Hz 0.00
√
F130 Skip Width B ±2.50 Hz 0.00
√
F131 Running Display Items
0: Output frequency /
function code
1: Output RPM
2: Output current
4: Output voltage
8: DC Bus voltage
16: PID feedback value
32: Temperature
64: Reserved
128: Linear speed
256: PID setpoint value
512: Reserved
1024: Reserved
2048: Output power
4096: Output torque
0+1+2+4+8
=15
√
F132
Display Items for Stop
Mode
0: Freq / function code
1: Keypad jogging
2: Target RPM
4: DC Bus voltage
8: PID feedback value
16: Temperature
32: Reserved
64: PID setpoint value
128: Reserved
256: Reserved
512: Setting torque
2+4=6
√
F133
Drive Ratio of Driven
System
0.10-200.0 1.0
√
F134
Transmission-wheel
Radius
0.001-1.000 0.001
√

Parker AC10 series Specifications

General

Overload Capacity	150% for 60 seconds
Analog Inputs	2
Analog Outputs	1
Communication Options	Modbus RTU
Protection Rating	IP20
Input Voltage	200-240VAC, 380-480VAC, 500-575VAC, 600VAC, 690VAC
Digital Outputs	2
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Humidity	5% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Braking	Built-in dynamic braking
