Parker AC10 series Quick Start Guide

Function
Code
Function Denition Setting Range Mfr’s Value Change
F135 Reserved
F136 Slip Compensation 0-10 0 X
F137 Torque Compensation Mode
0: Linear comp;
1: Quadratic comp;
2: User-dened
multipoint comp
3: Auto torque
comp
3 X
F138 Linear Compensation 1-20
Subject
to inverter
model
X
F139 Quadratic Compensation
1: 1.5; 2: 1.8;
3: 1.9; 4: 2.0
1 X
F140
F141
F142-
F152
User dened multipoint torque
comp function codes, refer to
Product Manual for settings
N/A N/A X
F153 Carrier frequency setting
Subject to inverter
model
Subject
to inverter
model
X
F154
Automatic voltage
rectication
Setting range:
0: Disabled
1: Enabled
2:Disabled during
decel process
0 X
F155 Digital secondary freq setting 0-F111 0 X
F156
Digital secondary freq
polarity setting
0-1 0 X
F157 Reading secondary freq
D
F158
Reading secondary freq
polarity
D
F159
Random carrier-wave freq
select
0: Control speed
normally;
1: Random carrier-
wave frequency
1
F160
Reverting to manufacturer
values (Factory Defaults)
0: Not reverting to
mfr values;
1: Reverting to mfr
values
0 X
10-3 Parameter List and Default Settings

Parker AC10 series Specifications

General

Overload Capacity	150% for 60 seconds
Analog Inputs	2
Analog Outputs	1
Communication Options	Modbus RTU
Protection Rating	IP20
Input Voltage	200-240VAC, 380-480VAC, 500-575VAC, 600VAC, 690VAC
Digital Outputs	2
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Humidity	5% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Braking	Built-in dynamic braking
