Parker AC10 series Quick Start Guide

Function
Code
Function Denition Setting Range Mfr’s Value Change
F200
Source of start
command
0: Keypad command;
1: Terminal command;
2: Keypad+Terminal;
3: MODBUS;
4: Keypad+Terminal+
MODBUS
4 X
F201
Source of stop
command
0: Keypad command;
1: Terminal command;
2: Keypad+Terminal;
3: MODBUS;
4: Keypad+Terminal+
MODBUS
4 X
F202
Mode of direction
setting
0: Forward run locking;
1: Reverse run locking;
2: Terminal setting
3: Keypad
0 X
F203
Main frequency source
(X)
0: Digital setting memory;
1: External analog AI1;
2: External analog AI2;
3: Reserved;
4: Stage speed control;
5: No memory by digital
setting;
6: Reserved;;
7: Reserved;
8: Reserved;
9: PID output;
10: MODBUS
0 X
F204
Secondary frequency
source (Y)
0: Digital setting memory;
1: External analog AI1;
2: External analog AI2;
3: Reserved;
4: Stage speed control;
5: PID adjusting;
6: Reserved;
0 X
F205
Reference for
selecting secondary
frequency source (Y)
range
0: Relative to max freq;
1: Relative to main freq (X)
0 X
F206
Secondary frequency
(Y) range
0-100% 100 X
Parameter List and Default Settings
10-4

Parker AC10 series Specifications

General

Overload Capacity	150% for 60 seconds
Analog Inputs	2
Analog Outputs	1
Communication Options	Modbus RTU
Protection Rating	IP20
Input Voltage	200-240VAC, 380-480VAC, 500-575VAC, 600VAC, 690VAC
Digital Outputs	2
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Humidity	5% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Braking	Built-in dynamic braking
