Parker AC20 Series User Manual

DOC-0017-04-EN: AC20 Series - Hardware Installation Manual
DOC-0017-04-EN-A 22.03.2023 131 (154)
Drive Type: 3ø, Fundamental Voltage = 400V
Line Inductance = 146µH, PSCC = 5kA
Frame Size:
8
9
Product Code:
20G-48-2200…
20G-48-2650…
20G-49-3200…
Power Rating (kW):
110
132
160
Current Rating (A):
220
265
320
Harmonic No.
RMS Current (A)
1
210.98
254.93
310.15
3
0.02
0.01
0.00
5
59.43
68.62
74.99
7
11.83
13.41
19.22
9
0.01
0.02
0.01
11
11.96
12.82
13.05
13
6.72
7.78
9.16
15
0.00
0.02
0.01
17
4.13
3.84
3.49
19
3.55
3.65
3.37
21
0.00
0.02
0.01
23
1.69
1.86
2.39
25
1.69
1.60
1.78
27
0.00
0.02
0.01
29
1.20
1.48
1.57
31
0.96
1.14
1.41
33
0.00
0.02
0.01
35
0.95
0.98
0.90
37
0.79
0.91
0.86
39
0.00
0.02
0.01
40
0.00
0.00
0.00
Total RMS Current (A):
220.00
264.80
320.10
THD: Current (%):
29.60
28.16
25.56
