DOC-0017-04-EN: AC20 Series - Hardware Installation Manual
DOC-0017-04-EN-A 22.03.2023 17 (154)
Product Fixing Dimensions
Frame
Size
Fixing Dimensions
Slot Size
Fixings H3 H4 W1 W2 K R1 R2
2
170.0
(6.69)
5.0
(0.20)
94.0
(3.70)
7.2
(0.28)
5.0
(0.20)
2.3
(0.09)
4.7
(0.19)
M4
3
225.0
(8.86)
6.5
(0.26)
126.0
(4.96)
7.8
(0.31)
6.0
(0.24)
3.0
(0.12)
5.3
(0.21)
M5
4
255.0
(10.04)
5.0
(0.20)
146.0
(5.75)
7.5
(0.30)
5.0
(0.20)
2.5
(0.10)
4.6
(0.18)
M5
5
329.0
(12.95)
5.5
(0.22)
194.0
(7.64)
8.0
(0.31)
6.0
(0.24)
3.0
(0.12)
5.5
(0.22)
M5
6
412.0
(16.22)
11.5
(0.45)
235.0
(9.25)
13.5
(0.53)
8.0
(0.31)
3.3
(0.13)
6.0
(0.24)
M6
7
605.0
(23.82)
15.0
(0.59)
320.0
(12.60)
17.5
(0.69)
10.0
(0.39)
4.5
(0.18)
9.0
(0.35)
M8
8
740.0
(29.13)
15.0
(0.59)
370.0
(14.57)
18.0
(0.71)
13.0
(0.51)
5.5
(0.22)
11.0
(0.43)
M10
9
740.0
(29.13)
12.5
(0.49)
360.0
(14.17)
75.0
(2.95)
13.0
(0.51)
5.5
(0.22)
10.5
(0.41)
M10
10
882.0
(34.72)
13.0
(0.51)
390.0
(15.35)
80.0
(3.15)
17.0
(0.67)
5.5
(0.22)
11.0
(0.43)
M10
All dimensions in millimeters (inches)
