Parker AC20 Series User Manual

DOC-0017-04-EN: AC20 Series - Hardware Installation Manual
DOC-0017-04-EN-A 22.03.2023 145 (154)
13.6 GPIO Option Card Ratings
Analogue Inputs
Terminal Idents:
AI3, AI4, referenced to 0V
Type:
Voltage Modes:
- ± 10V
- 0 – 10V
Maximum Input Voltage:
± 30V
Input Impedance:
10kΩ
Resolution:
15 Bit
Isolated:
No
Sample / Update Rate:
1msec
Analogue Outputs
Terminal Idents:
AO4, referenced to 0V
Type:
Voltage Mode:
- ± 10V
- 0 – 10V
Maximum Output
Current:
± 10mA
Typical Settling Time:
2.5msec (0 to 90%)
Resolution:
14 Bit
Isolated:
No
Short Circuit Protection:
Yes
Sample / Update Rate:
1msec
Digital Input
Terminal Idents:
DX11, referenced to 0V
Nominal Input Voltage:
24V
Maximum Input Voltage:
+ 30V
Input Thresholds:
Typical threshold = 10V:
- Low state <5V
- High state >15V
Input Current:
>2.5mA in High state
Typically: 5mA @ 24V
Isolated:
No
Sample Interval:
1msec
