Parker AC20 Series User Manual

DOC-0017-04-EN: AC20 Series - Hardware Installation Manual
12 (154) DOC-0017-04-EN-A 22.03.2023
5 Product Overview
General Overview:
Power Range:
1.5 – 180kW
Frame Sizes:
9 (Sizes 2 – 10)
Power Supply:
1ø 220 – 240Vac ±10%, (Frame 2: 1.5 – 2.2kW)
3ø 220 – 240Vac ±10%, (Frames 2 - 5: 1.5 – 11kW)
3ø 380 – 480Vac ±10%, (Frames 2 - 10: 1.5 – 180kW)
Input Frequency:
50/60Hz ±10%
Output Frequency:
0.5 – 590Hz
Safe Torque Off (STO):
SIL2, PLd
Environment:
Temperature:
0 - 40°C (derate output current above 40°C by 2% per °C, up to maximum
of 45°C)
Note: Anybus Options not suitable for use in temperatures >40°C.
Altitude:
0 – 1000m (derate output current above 1000m by 1% per 100m, up to
maximum of 2000m)
