13.2 AC Line Fed Power Stack Ratings
1ø, 230V Products
Power Supply = 1ø 220-240V ±10%, 50/60Hz ±10%, PSCC = 5kA
Motor power, output current and input current must not be exceeded under steady state operating
conditions.
Minimum repetitive power up / power down cycle time = 10 mins.
Frame
Size
Product Code
Motor
Power
(kW)
Output
Current
(A)
Input
Current
(A)
Est. Eff
(%)
Switching
Frequency
(kHz)
nom / max
AC
Current
Derate
(%/kHz)
2
20G-12-0070...
1.5
7
14
95
4 / 10
6.0
20G-12-0100...
2.2
10
20
96
4 / 10
6.3
3ø, 230V Products
Power Supply = 3ø 220-240V ±10%, 50/60Hz ±10%, PSCC = 5kA
Motor power, output current and input current must not be exceeded under steady state operating
conditions.
Minimum repetitive power up / power down cycle time = 10 mins.
Frame
Size
Product Code
Motor
Power
(kW)
Output
Current
(A)
Input
Current
(A)
Est. Eff
(%)
Switching
Frequency
(kHz)
nom / max
AC
Current
Derate
(%/kHz)
2
20G-32-0070...
1.5
7
7.8
95
4 / 10
6.0
20G-32-0100...
2.2
10
11
95
4 / 10
6.2
3
20G-33-0170...
4
17
18.5
96
4 / 10
4.8
4
20G-34-0210...
5.5
21
22
97
4 / 10
2.2
5
20G-35-0300...
7.5
30
31
97
4 / 10
3.2
20G-35-0400...
11
40
41
97
4 / 10
2.0
3ø, 400V Products
Power Supply = 3ø 380-480V ±10%, 50/60Hz ±10%, PSCC = 5kA
Motor power, output current and input current must not be exceeded under steady state operating
conditions.
Minimum repetitive power up / power down cycle time = 10 mins.
Frame
Size Product Code
Motor
Power
(kW)
Output
Current
(A)
Input
Current
(A)
Est. Eff
(%)
Switching
Frequency
(kHz)
nom / max
AC
Current
Derate
(%/kHz)
2
20G-42-0040...
1.5
4
5
95
4 / 10
10.2
20G-42-0065...
2.2
6.5
7.5
95
4 / 10
8.3
20G-42-0090...
4
9
11
96
4 / 10
7.2
3
20G-43-0120...
5.5
12
14
96
4 / 10
7.8
20G-43-0170...
7.5
17
18.5
96
4 / 10
6.3
4
20G-44-0230...
11
23
24
97
4 / 10
5.0
20G-44-0320...
15
32
36.5
97
4 / 10
4.5
5
20G-45-0380...
18.5
38
44
97
4 / 10
4.0
20G-45-0440...
22
44
51
98
4 / 10
5.3
20G-45-0600...
30
60
70
96
4 / 10
5.8
6
20G-46-0750…
37
75
80
96
4 / 10
3.3
20G-46-0900…
45
90
94
96
4 / 6
4.5
7
20G-47-1100…
55
110
120
97
3 / 8
5.0
20G-47-1500…
75
150
160
97
3 / 8
4.6
