Frames 7 – 10:
Frame
Size
Product Dimensions
Weight
H
H1
H2
W
D
7
630.0
(24.80)
623.5
(24.55)
n/a
355.0
(13.98)
265.0
(10.43)
36.0
(79.37)
8
765.0
(30.12)
755.0
(29.72)
n/a
406.0
(15.98)
300.0
(11.81)
52.0
(114.64)
9
765.0
(30.12)
778.0
(30.63)
n/a
510.0
(20.08)
326.0
(12.83)
83.0
(182.98)
10
910.0
(35.83)
925.0
(36.42)
n/a
550.0
(21.65)
341.5
(13.44)
100.0
(220.46)
All dimensions in millimeters (inches)
All weights in kilograms (lbs)
