Parker AC20 Series User Manual

DOC-0017-04-EN: AC20 Series - Hardware Installation Manual
44 (154) DOC-0017-04-EN-A 22.03.2023
On Frames 6 – 10, the lower terminal cover will need to be removed prior to connecting the Ethernet cable
into the RJ45 socket on the control PCB.
To remove the cable, push the connector clip down towards the cable and pull.
1. Insert the cable connector,
clip side up, into the RJ45 port
on control PCB.
