DOC-0017-04-EN: AC20 Series - Hardware Installation Manual
DOC-0017-04-EN-A 22.03.2023 55 (154)
Frames 6 – 10:
On Frames 6 – 10, the lower terminal cover will need to be removed prior to µSD card installation in the
control PCB.
To remove the card, pull it out the slot.
1. Insert the µSD Card label side up
in the orientation shown, into the
connector located on the left-hand
side of the control PCB.
