PCAN-Ethernet Gateway FD DR – User Manual
18
5. ListenOnlyMode: If the PCAN-Gateway should act as a
pure observer, not affecting the data traffic, Listen-Only-
Mode must be enabled. Activate Listen-Only-Mode with a
click on the checkbox.
6. Confirm the entries with Save Settings.
3.2.3 Connecting to a LAN Network
Do the
following to configure the IP address data of the PCAN-
Gateway for the LAN network to be connected:
Manual Address Assignment (Recommended)
1. Open the page Network > LAN.
2. If automatic address assignment via DHCP is not used, enter
the IP address and Subnet mask that the PCAN-Gateway
should use in the LAN network at the bottom of the page.
The gateway address can optionally be set.
3. Confirm the entered data with Save Settings.
You are automatically forwarded to the new IP address. The
basic setup of the device is now completed.
Automatic Address Assignment via DHCP
Note: DHCP is not recommended, because it is necessary to
know the IP address of the device to access the configuration
website. Furthermore, the IP address may change after a restart
of the device or the DHCP server. In this case the existing
routes won't work.
1. Open the page Network > LAN.
2. If the future LAN network uses DHCP (Dynamic Host
Configuration Protocol), the PCAN-Gateway IP address and
