PCAN-Ethernet Gateway FD DR – User Manual
15
Do the following to change your IP address:
1. Make a note of the current settings in order to reset the
computer later on.
2. Select Use the following IP address.
3. Enter an IP address in the range from 192.168.1.1 to
192.168.1.254 (but not the PCAN-Gateway's own address
which is indicated on the left casing side).
4. Click on Subnet mask. 255.255.255.0 is shown. Leave this
entry unchanged.
5. Confirm the entries with OK.
3.1.2 Establishing the Connection
Do the
following to establish a connection:
1. Connect the RJ-45 connector of the PCAN-Gateway via a
LAN cable (included in the scope of supply) directly to the
computer.
2. Connect the device to a suitable power supply (8 - 30 V).
3. Wait until the PCAN-Gateway is ready (Status LED is
blinking green).
4. Open a web browser on the computer.
5. In the browser's address bar, enter the address of the PCAN-
Gateway (see the label on the left side of the device).
