PCAN-Ethernet Gateway FD DR – User Manual
17
3.2 Basic Configuration
Change your login data first and then set up the PCAN-Gateway
connection to CAN and the LAN network.
3.2.1 Change Login Data
1. O
pen the page Device > User Management.
2. Change the login data on this page. Create a new username
and a new password.
To ensure a minimum level of security, the password should
have at least 8 characters. If possible, use letters, numbers,
and special characters.
Important notice: Login data is confidential! Do not act care-
lessly and leave your system open to attack. Never deposit the
login data in any form on the Internet or make it easily
accessible. Do not give the new login data carelessly to third
parties nor send it by e-mail.
3.2.2 Setting up CAN Channels
Do t
he following to configure the CAN channels:
1. Open the page Network > CAN.
2. Nominal Bit Rate: For setting the nominal bit rate, click the
drop-down menu and select the value that is used on the
CAN bus to be connected.
3. CAN FD: If the CAN bus to be connected uses the new
standard CAN FD, activate the checkbox CAN FD. The form
for selecting the data bit rate appears.
4. Data Bit Rate: For setting the data bit rate, click the drop-
down menu and select the value that is used on the CAN
bus to be connected.
