PCAN-Ethernet Gateway FD DR – User Manual
40
5.4 Filters
Filters are used to filter CAN messages by their ID. It is possible to
create up to 32 of them. Each filter can be attached to multiple Send
routes via the page
Add Route
or
Edit Route
.
The page
Filters
displays basic information about the created filters.
Defined Filters:
This box contains an overview of all defined filters with basic
information. Starting with the index, every filter is displayed with its
usage, user notes, name, type, and mode.
On the
Filter > Manage Filters
page, existing filters can be
managed, edited, and deleted
On the
Filter > Add Filter
page, new filters can be created
5.4.1 Manage Filters
On the
page
Filters > Manage Filters
the existing filters are listed
with basic information and control options. Each of them is
specified with its index, usage, user notes, name, type, and mode.
Index: For saving filters, the PCAN-Gateway uses a table with 32
rows that are addressed with this unique index.
Usage: The badge on the left shows how many times the filter is
used. The information to which routes it is attached to, is displayed
as a tooltip when hovering with the mouse cursor. The list refers to
the indices of the routes. If you click on the badge, the page
Manage
Routes
will be opened with the corresponding routes highlighted.
Notes: Hover this icon with the mouse cursor to display the user
notes of this filter. The icon is not visible if no user notes are
available.
