PCAN-Ethernet Gateway FD DR – User Manual
70
7 Technical Specifications
Connectors
Power Phoenix connector 4-pin
2
CAN 2 x Phoenix connector 4-pin
2
LAN RJ-45 socket
RS-232 Phoenix connector 4-pin
2
USB downstream USB port type A 3.0
High-speed USB 2.0 downstream
(compatible with USB 1.1 and USB 3.0)
Max. current output 1.5 A
MiniPCIe Slot for an expansion card in MiniPCie format
Power Supply
Operating voltage 8 – 30 V DC
Supply type External supply unit
Current consumption 800 mA at 8 V
300 mA at 12 V
250 mA at 30 V
Protection Overvoltage protection: ± 32.5 V surge
Reverse polarity protection: 35 V
RTC backup supply Goldcap
CAN (FD)
Protocols on OSI layer 2 CAN FD ISO 11898-1:2015, CAN FD non-ISO,
CAN 2.0 A/B
Physical transmission ISO 11898-2 (High-speed CAN)
Transceiver MCP2558FD
CAN bit rates Nominal: 20 kbit/s - 1 Mbit/s
CAN FD bit rates Nominal: 20 kbit/s - 1 Mbit/s
Data: 20 kbit/s - 10 Mbit/s
3
Controller FPGA implementation
2
Mating Connector Phoenix Contact MSTB 2,5/4-ST BK - 1756298
3
According to the CAN transceiver data sheet, only CAN FD transfer rates up to 8
Mbit/s are guaranteed with the specified timing.
