PCAN-Ethernet Gateway FD DR – User Manual
25
When the restore partition is activated, the IP address is
reset to 192.168.1.10 and DHCP is additionally activated. If a
DHCP server is available, an additional IP address is
automatically assigned to the device, via which it can be
reached too.
3. Connect the device to your computer (described in chapter
3.1 on page 14).
4. O
pen the IP address in a browser.
The Restore website appears.
Note: If the boot process on both partitions cannot be executed
completely 10 times in a row or is interrupted by voltage loss,
the PCAN-Ethernet Gateway FD DR automatically activates the
restore partition.
Functionality of the Restore Website:
The Restore website offers various functions for analyzing the
partitions or for restoring the device:
Indicating the software version and IP connection information
Downloading the configuration file
Activating and rebooting of a partition
Installing new software and resetting to factory defaults
Note: When a new software is installed, it is applied to both
partitions. The IP address and the login data are reset to the
initial values (see the label on the left side of the PCAN-
Gateway). Afterwards, you can perform a reconfiguration of the
PCAN-Gateway (see chapter 3 on page 14).
