PCAN-Ethernet Gateway FD DR – User Manual
29
The main pages (Status, Routing, Filters, Network, Device, Help,
and Support) display general information
The subpages of
Network
and
Device
provide configuration
options for the communication interfaces and the device
The subpages of
Routing
can be used to add, manage, edit, or
delete routes, as well as to search for other devices in the
network
The subpages of
Filters
can be used to add, edit, or delete filters
The links in the control box (below the menu) perform additional
website and device functions.
Refresh: Clicking Refresh will perform a page reload, for
example to update the current route status
Note: The information displayed on the website is not updated
automatically by default.
Auto Refresh On / Off: When you activate this function by left
clicking the link, the website will begin to automatically update
the information on the page every 10 seconds. You can
manually turn this function off by left clicking the link again.
Navigating away from the current page will automatically
deactivate this function too
Illuminate: One or more LEDs on the device will light up for
approximately 10 seconds. This function can be used to identify
the device
Reboot Device: Use this link to restart the device. During this
process, the PCAN-Gateway is unreachable
The red framed Info box at the end of the navigation lists important
information about the current configuration.
