PCAN-Ethernet Gateway FD DR – User Manual
38
Frames per Packet: This value specifies how many CAN frames are
transmitted per IP packet. The higher the value, the greater the
delay in the transmission of CAN messages. However, the demand
on performance is lower in this case. This selection is only available
for Send routes when using the UDP protocol.
TCP Delay: (Expert mode only) If this checkbox is active, TCP delay
is enabled. In this case, the transmission of data packets via TCP
might be delayed to lower the demand on performance. If this
option is disabled, every CAN frame is transmitted as fast as
possible.
Filter:
The defined filters are listed in this form. A single one can be
attached or detached to Send routes via the radio buttons. If Expert
mode is active, the radio buttons will be replaced with checkboxes
and multiple filters can be selected.
Filters are joined with: This property specifies how multiple filters
are linked. If you use several Whitelist filter, you should choose
Logical OR. If you attach multiple Blacklist filter to a single route, the
selection Logical AND is recommended.
Note: A single
Range
filter is realized with a composition of
multiple
Mask
filters. The Joined Filters property will also affect
this.
User Notes:
Additional information with a length of 125 characters can be
entered for each route. This text is available on the page
Routing >
Manage Routes
.
Finally you can create a new route with the Add Route button or
save the changes after editing with the Save Settings button.
